Product Properties

THRED Magnets TOPS or Regular Magnets

Magnet Grade	THRED Magnetic Charcateristics
	Remanence B_r				Coercivity H_cJ		Coercivity H_cB		Maximum Energy Product (BH)_max				Temperature Coefficient	Temperature Coefficient	Relative Recoil Permeability μ_rec	Maximum Working Temperature	Density ρ
	kGs		T		kOe	kA/m	kOe	kA/m	MGOe		kJ/m³		%/℃	%/℃	Relative Recoil Permeability μ_rec	℃	℃
	Max.	Min.	Max.	Min.	Min.	Min.	Min.	Min.	Max.	Min.	Max.	Min.	Typ.	Typ.	Typ.	(L/D=0.7) Typ.	Typ.
G56SH		14.6		1.46	20	1592	13.7	1091	57	52	454	414	-0.105	-0.55	1.05	150	7.45
G54SH	15.0	14.4	1.50	1.44	20	1592	13.5	1075	55	50	438	398	-0.105	-0.55
G52SH	14.8	14.2	1.48	1.42	20	1592	13.3	1059	53	49	422	390	-0.105	-0.55
G50SH	14.6	14.0	1.46	1.40	20	1592	13.1	1043	51	47	406	374	-0.105	-0.55
G48SH	14.3	13.7	1.43	1.37	20	1592	12.8	1019	49	45	390	358	-0.105	-0.55
G46SH	13.9	13.3	1.39	1.33	20	1592	12.5	995	47	43	374	342	-0.105	-0.55
G44SH	13.6	13.0	1.36	1.30	20	1592	12.2	971	45	41	358	326	-0.105	-0.55
G54UH	15.0	14.4	1.50	1.44	25	1990	13.5	1075	55	50	438	398	-0.110	-0.50		180	7.50
G52UH	14.8	14.2	1.48	1.42	25	1990	13.3	1059	53	49	422	390	-0.110	-0.50
G50UH	14.6	14.0	1.46	1.40	25	1990	13.1	1043	51	47	406	374	-0.110	-0.50
G48UH	14.3	13.7	1.43	1.37	25	1990	12.8	1019	49	45	390	358	-0.110	-0.50
G46UH	13.9	13.3	1.39	1.33	25	1990	12.5	995	47	43	374	342	-0.110	-0.50
G44UH	13.6	13.0	1.36	1.30	25	1990	12.2	971	45	41	358	326	-0.110	-0.50
G40UH	13.2	12.6	1.32	1.26	25	1990	11.8	939	42	38	334	302	-0.110	-0.50
G50EH	14.6	14.0	1.46	1.40	30	2388	13.1	1043	51	47	406	374	-0.110	-0.50		200	7.55
G48EH	14.3	13.7	1.43	1.37	30	2388	12.8	1019	49	45	390	358	-0.110	-0.50
G46EH	13.9	13.3	1.39	1.33	30	2388	12.5	995	47	43	374	342	-0.110	-0.50
G44EH	13.6	13.0	1.36	1.30	30	2388	12.2	971	45	41	358	326	-0.110	-0.50
G42EH	13.5	12.9	1.35	1.29	30	2388	12.1	963	44	40	350	318	-0.110	-0.50
G40EH	13.2	12.6	1.32	1.26	30	2388	11.8	939	42	38	334	302	-0.110	-0.50
G35EH	12.4	11.7	1.24	1.17	30	2388	10.9	868	37	33	295	263	-0.110	-0.50
G44AH	13.6	13.0	1.36	1.30	35	2786	12.2	971	45	41	358	326	-0.115	-0.45		230	7.55
G42AH	13.5	12.9	1.35	1.29	35	2786	12.1	963	44	40	350	318	-0.115	-0.45
G40AH	13.2	12.6	1.32	1.26	35	2786	11.8	939	42	38	334	302	-0.115	-0.45
G35AH	12.4	11.7	1.24	1.17	35	2786	10.9	868	37	33	295	263	-0.115	-0.45
G30AH	11.5	10.8	1.15	1.08	35	2786	10.1	804	32	28	255	223	-0.115	-0.45
G28ZH	11.1	10.4	1.11	1.04	40	3184	9.7	772	30	26	239	207	-0.115	-0.45		250	7.60

As magnetic property might be changed by dimensions and/or shapes, some magnet design might not refer to the above property.

Magnet Grade	Remanence B_r				Coercivity H_cJ		Coercivity H_cB		Maximum Energy Product (BH)_max				Temperature Coefficient	Temperature Coefficient	Relative Recoil Permeability μ_rec	Maximum Working Temperature	Density ρ
	kGs		T		kOe	kA/m	kOe	kA/m	MGOe		kJ/m³		%/℃	%/℃	Relative Recoil Permeability μ_rec	℃	g/cm³
	Max.	Min.	Max.	Min.	Min.	Min.	Min.	Min.	Max.	Min.	Max.	Min.	Typ.	Typ.	Typ.	(L/D=0.7)Typ.	Typ.
ZHN55N		14.7		1.47	11	876	10.5	836		52		414	-0.100	-0.75	1.05	80	7.45
ZHN53N	15.0	14.4	1.50	1.44	11	876	10.5	836	54	50	430	398	-0.100	-0.75
ZHN50N	14.6	14.0	1.46	1.40	11	876	10.5	836	51	47	406	374	-0.100	-0.75
ZHN48N	14.3	13.7	1.43	1.37	11	876	10.5	836	49	45	390	358	-0.100	-0.75
ZHN54M	15.0	14.4	1.50	1.44	14	1114	13.5	1075	55	51	438	406	-0.100	-0.65		100	7.45
ZHN52M	14.8	14.2	1.48	1.42	14	1114	13.3	1059	53	49	422	390	-0.100	-0.65
ZHN50M	14.6	14.0	1.46	1.40	14	1114	13.1	1043	51	47	406	374	-0.100	-0.65
ZHN48M	14.3	13.7	1.43	1.37	14	1114	12.8	1019	49	45	390	358	-0.100	-0.65
ZHN52H	14.8	14.2	1.48	1.42	16	1274	13.3	1059	53	49	422	390	-0.105	-0.55		120	7.5
ZHN50H	14.6	14.0	1.46	1.40	16	1274	13.1	1043	51	47	406	374	-0.105	-0.55
ZHN48H	14.3	13.7	1.43	1.37	16	1274	12.8	1019	49	45	390	358	-0.105	-0.55
ZHN46H	13.9	13.3	1.39	1.33	17	1353	12.5	995	47	43	374	342	-0.105	-0.55
ZHN44H	13.6	13.0	1.36	1.30	17	1353	12.2	971	45	41	358	326	-0.105	-0.55
ZHN42H	13.5	12.9	1.34	1.28	17	1353	12.1	963	44	40	350	318	-0.105	-0.55
ZHN40H	13.2	12.6	1.32	1.26	17	1353	11.8	939	42	38	334	302	-0.105	-0.55
ZHN48SH	14.3	13.7	1.43	1.37	20	1592	12.8	1019	49	45	390	358	-0.105	-0.55		150	7.5
ZHN46SH	13.9	13.3	1.39	1.33	20	1592	12.5	995	47	43	374	342	-0.105	-0.55
ZHN44SH	13.6	13.0	1.36	1.30	20	1592	12.2	971	45	41	358	326	-0.105	-0.55
ZHN42SH	13.5	12.9	1.35	1.29	20	1592	12.1	963	44	40	350	318	-0.105	-0.55
ZHN40SH	13.2	12.6	1.32	1.26	20	1592	11.8	939	42	38	334	302	-0.105	-0.55
ZHN38SH	12.9	12.2	1.29	1.22	20	1592	11.4	907	40	36	318	287	-0.105	-0.55

1. As magnetic property might be changed by dimensions and/or shapes, some magnet design might not refer to the above property.
2.Temperature range to determine the temperature coefficient: ΔT: 20℃～80℃ for N grades; ΔT: 20℃～100℃ for M grades; ΔT: 20℃～120℃ for H grades; ΔT: 20℃～150℃ for SH grades; ΔT: 20℃～180℃ for UH grades; ΔT: 20℃～200℃ for EH grades; ΔT: 20℃～230℃ for AH grades; ΔT: 20℃～250℃ for ZH grades.
